SPECIFICATIONS

Brand Name: CHANZON
Certification: UL,RoHS
Choice: yes
High-concerned chemical: None
Model Number: Insulated Cord Splice Disconnect Solderless Copper Wiring Connector
Origin: Mainland China
Type: 22 16 14 12 10 22-16 16-14 12-10 20 Awg Gauge Crimping Joint Kit Tool
is_customized: Yes

50/70Pcs Piggy Back Wire Connectors 6.3Mm Piggyback Cord Disconnect Crimp Splice Wirefy Electrical Solderless Terminals 22-10AWG
Description:
Product Name:Piggy Back Wire Connectors
Material:Pvc,Copper
Red=Awg 22-16 (0.5-1.5Mm²)
Blue=Awg 16-14 (1.5-2.5Mm²)
Yellow=Awg 12-10(4-6Mm²)
Rated Voltage:300V
70Pcs Kit Package Included:
30Pcs X Red
30Pcs X Blue
10Pcs X Yellow
Feature:
-Easy Installation, And A Low Installed Cost, Which Is More Reliable Than Conventional Crimp Terminals.
-Providing Strain Relief And Against Vibration In Rugged Environment, Which Insulates And Protects Electrical Connections.
-In The Middle Of The Splice Is High Pure Copper Tube, With Excellent Conductivity Property.
-Excellent Stretch, Puncture And Mechanic Damage Resistance Performance.
-Fully Insulated Connectors, Tin-Plated Copper With Pvc Insulation.
